PRODUCT DETAILS

—

1. Breakaway has the function offast sealing with safety and reliability

2. Breakaway can be assembled to reuse after being pulled off a nd its maintenance cost is low

PRODUCT DATA

—

●    Let pressure: 5~20MPa

●    Haust pressure: 45/87.5MPa

●    Filling pressure: 35/70MPa

●    Filling temperature: - 10 ℃/- 40 ℃

●    Daily filling capacity: 200-1000kg/ d@12.5MPa

产品参数

主要用途

The T13 series high-pressure hydrogen breakaway coupling is a safety protection product designed to prevent the hydrogen refueling hose or other parts from being damaged by abnormal external forces. In order to meet the requirements for different specifications of refueling caliber, the breakaway coupling integration of two specifications and two types has been formed, in which the T136 breakaway coupling is to match the small-caliber hydrogen refueling nozzle and the T137 breakaway coupling is to match the large-caliber hydrogen refueling nozzle.
